圆筒筛
一、用途
圆筒筛主要用于废纸制浆,清除流程中形状较大的轻杂物。
具有筛选效果好,动力消耗低,结构简单,维修方便等优点。
二、结构原理
圆筒筛主要由筛鼓、箱体、齿轮减速电机及喷水管系统等组成。筛鼓内有螺旋形叶片,对杂质具有输送作用。含有浆料的轻杂质由进浆口进入筛鼓内,在重力的作用下,良浆通过筛孔从良浆口排出,轻杂质由筛鼓内的螺旋叶片输送至筛鼓尾部排出。喷水系统安装在筛鼓内两侧,一方面对杂质中的浆料清洗,另一方面对筛鼓进行冲洗,保持筛孔通畅。
Drum Screen is mainly used for pulping from the waste papers and clearing the light impurities with larger shape in the process.
Features of Drum Screen:
Drum Screen has a good screening effect, low power consumption, simple structure and easy maintenance, etc.
Technical parameters of Drum Screen:
Model | ZST1A | ZST2A | ZST4A |
Diameter of screen drum (mm) | Φ1000 | Φ1500 | Φ2000 |
Carrying capacity (L/min) | 3000-5000 | 6000-8000 | 9000-12000 |
Motor power (KW) | 4 | 5.5 | 11 |
