抓斗

抓斗在连续碎解系统中,与起吊设备配合使用,将沉渣井中的轻重杂质定时抓出。
抓斗主要由气缸,四个斗瓣和连杆组成。与沉渣井配套, 组成杂质去除系统。
抓斗下降时,斗瓣开启,斗口张至最大尺寸。调整抓斗降落位置,于沉渣井浆液上部,可去除轻杂质,于沉渣井浆液下部,可去除重杂质。
抓斗的额定负荷量可达300Kg。
结构
抓斗体由四个斗瓣,气缸,连杆,提升吊环座,销轴,气缸固定壳,铰链等组成。
附属装置有:气动三联体,二位四通电磁换向阀,气源等组成。
气体经气动三联体清洁,油雾后,进入气缸,活塞杆经铰链机构带动斗瓣旋转。闭合抓取杂质,开启卸掉杂质。



Grapple is used together with the lifting equipment in the continuous disintegration system to grapple the light and heavy impurities of sediment trap periodically. The grappler is composed of cylinder, four flaps and connecting rod, and it is matched with sediment trap to form the impurity removal system.

Features of Grapple:
When Grapple drops, the flaps open and the grapple mouth stretches to a maximum size. When the landing position of the grapple is adjusted on the upper part of the pulp in sediment trap, it can remove the light impurities, while adjusted on the lower part of the pulp in sediment trap, it can remove the heavy impurities. The rated load of the grapple can be up to 300 Kg.
